Allevi 1
Small Footprint, Big Impact
Play Video
Nozzle Auto-calibration
Gone are the days of manually calibrating your extruder before getting started with your print. Simply press auto-calibrate and let the Allevi 1 bioprinter do all of the work.
Allevi CORE-Compatible
The Allevi 1 is designed for use with the Allevi CORE removable extruder system, which accepts 5mL plastic or metal luer lock syringes and is optimized for all of the bioinks we offer.
Adjustable Photocuring
With the Allevi 1 bioprinter, you can choose to cure biomaterials in either visible or ultraviolet light. The extruder houses two separate LEDs in the ranges of 365nm and 405nm.
UV / Blue Light
4˚ – 160˚ C
Flexible Temperature Control
With cooled and heated temperature control from 4° C to 160° C, the Allevi 1 bioprinter is able to print a wide range of bioinks including collagen solutions, matrigel solutions, gelatin methacrylate, alginate, graphene, carbohydrate glass, polycaprolactone (PCL), and PLGA – just to name a few.
Pneumatic Extrusion
The Allevi 1 is built around a compressed air pneumatic system, making it very easy to achieve clean starts and stops in printing. Pressure ranges between 3 and 100 PSI accommodate a wide range of material viscosities.
Previous
Next
TECHNICAL SPECIFICATIONS
-
Extruders 1 × Allevi CORE Extruder
-
Photocuring LED – 365nm and 405nm
-
Printing Technology Fused Deposition Manufacturing (FDM)
-
Compatible Syringes 5 mL plastic, 5 mL metal
-
Min. Temp 4˚ C
-
Max. Temp 160˚ C
-
Min. Pressure 3 PSI
-
Max. Pressure 100 PSI
-
Pressure Variance ±1 PSI
-
Construction Aluminum Frame
-
X, Y Precision 7.5 μm
-
Z Precision 1 μm
-
Build Volume (W × H × D) 3.5 × 2.4 × 5.1 in (42.8 in³)
-
Build Volume Metric (W × H × D) 9 × 6 × 13 cm (702 cm³)
-
Supported Build Plates Slide, Petri Dish, Well Plate
-
Dimensions (W × H × D) 11.8 × 11.2 × 10.8 in
-
Dimensions Metric (W × H × D) 30.0 × 28.3 × 27.5 cm
-
Weight 15.5 lbs (7.0 kg)
-
Power Requirements AC 110V – 220V
